Scope of Application

The textile formaldehyde content tester is used to determine formaldehyde content in various textiles and garment fabrics. It employs water extraction method to prepare formaldehyde solution, followed by colorimetric reaction with Nash reagent, and final testing through software analysis.

Mandatory Standards in China

China’s national mandatory standard GB 18401-2003 (Basic Safety Technical Specifications for Textiles) has been implemented since January 1, 2006, specifying safety requirements for harmful substances including formaldehyde. Additional standards effective since January 1, 2010 include:

• GB/T 23328-2009 – Machine-woven student uniforms
• GB/T 2664-2009 – Men’s suits and coats
• GB/T 2665-2009 – Women’s suits and coats
• GB/T 2666-2009 – Trousers
• GB/T 23314-2009 – Neckties

Applicable International Standards

GB/T 2912; AATCC 112; BS 6806; DIN EN ISO 14184.2

Core Advantages

• 128×64-bit LCD display with clear readability and stable accuracy
• Continuous testing & storage for 200 sets of data (5 displayed per screen)
• C-Mode: Built-in multi-point standard curve creation and unknown sample analysis
• F-Mode: Direct measurement using custom curve coefficients
• 200 stored standard curves with instant recall by number
• Power-off data retention functionality
• Automatic wavelength calibration with self-repair system
• Plug-and-play deuterium/tungsten lamps (no optical realignment needed)
• Optional quantitative software for photometric analysis and data processing
