Alcohol Burner Combustion Tester
Category：Flammability Tester
Introduction
The Alcohol Burner Combustion Tester is designed for laboratory testing of non-metallic products, particularly polymers used in coal mining, to determine their flame-retardant performance. The instrument allows accurate measurement of burning time, flame height, and combustion behavior under controlled conditions, ensuring compliance with industry standards.
Application
Its main purpose is to determine the flame retardant performance of polymer products used in coal mines, allowing polymer product manufacturers to test the flame retardant performance of various types of flame-retardant products. It is widely used in fields such as building materials, textiles, rubber, plastics, wood, and polymers.
Standards
MT182: Alcohol blast burner structure and technical requirements
MT141: Cefminox sodium
MT914: Textile fire resistant conveyor belting for coalmine
Parameters
| Item | Description |
|---|---|
| Combustion Time | 0–9999 seconds, adjustable (standard: 30 seconds) |
| Flame & Blazing Timer | 0–9999 seconds, accuracy: +0.1 seconds |
| Combustion Test Chamber Size | 660mm x 660mm x 1065mm |
| Fuel Composition | 5%(V/V) methanol and 95%(V/V) ethanol mixture |
| Flame Height | 150mm–180mm, adjustable |
| Fuel Consumption | 2.55 ± 0.15 mL/min |
| Alcohol Blowtorch Type | Hanging type |
| Automatic Timing Features | Automatic timing of burning time and open flame/blazing time |
| Flame Adjustment | Flame height adjustable |
| Chamber Construction | Steel plate electrostatic spraying box with ventilation device |
| Fire Nozzle Material | Pure copper, equipped with preheating tank for simple operation |
| Flame Adjustment Device | Can test flame height according to standard requirements |
| Firehead Manual Handle | Safe and convenient for moving the firehead |
| Inner Box Color | Pure black (standard requires dark inner box) |
| Fuel Composition (Customer Provided) | 5%(V/V) methanol and 95%(V/V) ethanol mixture |
| Weight | 60 KG |
| Packing Volume | 0.85 cubic meters |
Features
1. Alcohol burner fit to standard required;
2. Burning time is recorded automatic;
3. The flame height can be adjusted;
4. With a special exhaust system, exhaust gas discharged automatically.
Accessoriess
Made of pure copper, the burner head features a preheating groove for easy preheating operation;
Equipped with a flame adjustment device, allowing for testing of flame height according to standard requirements;
Includes a manual handle for the burner head, making it safe and convenient to move the burner head.
FAQ
1. What is this product?
It is a laboratory tester for evaluating the combustion performance of non-metallic materials using an alcohol burner.
2. What is this product used for?
To measure flame-retardant performance, burning time, and flame height of polymer and other non-metallic products.
3. What is the working principle of this product?
A controlled alcohol flame is applied to the specimen, and the system records burning time and flame behavior while safely venting combustion gases.
4. Why is this product important?
It ensures the fire safety of polymer products, especially for coal mining applications, and verifies compliance with national safety standards.
5. What industries is this product suitable for?
Coal mining, building materials, textiles, rubber, plastics, wood, and polymer product manufacturing.
