Computer Controlled Torque Rheostat Tester
Category：Universal Strength Tester
Introduction
The Computer Controlled Torque Rheostat Tester simulates industrial mixing on a lab scale. A material sample in a heated chamber with rotating blades generates torque as it resists rotor motion. A transducer measures this torque in real-time. The computer controls chamber temperature and rotor speed per a test profile, presenting data as a torque-time curve for analyzing material behavior.
Application
Materials Science: An ideal instrument for studying the flow, plasticity, thermal, and shear stability of materials.
Food Industry: Used to test the rheological properties of food materials, such as the mixing of multi-component materials, the cross-linking and curing of thermosetting resins, and the vulcanization of elastomers.
Chemical Industry: Used to study the rheological characteristics of chemical materials, such as the rheological properties of polymer melts, suspensions, coatings, inks, and food.
Geological Engineering: Used for rheological characterization of geological materials, such as the flow and deformation characteristics of rocks and soils.
Standard
(1)ASTM D2538: Standard Practice for Fusion of Poly(Vinyl Chloride) (PVC) Compounds Using a Torque Rheometer
(2)ISO 305: Plastics – Determination of thermal stability of poly(vinyl chloride), related chlorine-containing homopolymers and copolymers and their compounds – (3)Discoloration method
Parameters
| Feature/Specification | Details |
|---|---|
| Peak Measurement Range | 50 Nm (100 Nm, 200 Nm, 300 Nm, 500 Nm available on request) |
| Test Modes | Track, Peak, Auto-Peak |
| Test Accuracy | ±0.5% |
Advantages
(1)Characterizes Material Processability: Provides direct measurement of how materials behave during mixing and processing under controlled conditions.
(2)Evaluates Thermal and Shear Stability: Helps determine a material’s resistance to degradation under heat and mechanical stress.
(3)Simulates Industrial Processes: Replicates key aspects of industrial mixing, extrusion, and other processing operations on a laboratory scale.6
(4)Objective and Quantitative Data: Generates precise torque-time curves and other data for analysis and comparison.
(5)Computer Controlled Precision: Automated control of temperature, speed, and test duration ensures high repeatability and accuracy.
(6)Versatile for Various Materials: Applicable to a wide range of polymers, elastomers, ceramics, food products, and other materials that undergo viscous processing.
(7)Supports R&D and Quality Control: Essential tool for material development, formulation optimization, and ensuring consistent product quality.
(8)Identifies Material Behavior Stages: The torque curve clearly shows different phases of material transformation during processing (e.g., melting point, fusion time, degradation onset).
Accessoriess
(1)One instruction manual
(2)One certificate of conformity
(3)One calibration certificate
FAQ
1. What is a Computer Controlled Torque Rheostat Tester used for?
It measures torque characteristics and resistance changes in rheostats and rotary devices, providing precise and automated test data.
2. How does the tester operate?
The machine uses computer control to apply torque to the device under test while recording resistance and torque values in real time.
3. What types of devices can be tested?
Commonly used for rotary rheostats, potentiometers, switches, and other devices that require torque-resistance profiling.
4. How is test data recorded and analyzed?
Test results are collected digitally and can be displayed, stored, and exported for analysis using the accompanying software.
5. What maintenance is required for this tester?
Routine checks include cleaning, lubrication of moving parts, calibration, software updates, and inspection of cables and connectors.
