Elastic fatigue testing machine
Category：Fatigue Tester, Products
Introduction
Product Introduction:
This instrument is used to test the elasticity of elastic belt after reciprocating movement.
The Elastic Fatigue Testing Machine is designed to evaluate the durability of elastic materials such as tapes, bands, and fabrics under repeated stretching. This machine subjects specimens to a continuous cycle of extension and retraction up to a pre-set maximum elongation, simulating real-world usage and wear. By counting the number of cycles until failure or a specified degradation point, it accurately determines the fatigue resistance and lifespan of the elastic material. This tester is crucial for quality control in industries producing textiles, medical devices, and sportswear, ensuring the long-term performance and reliability of elastic components.
Product Specifications:
1. Sample set: 1 set
2. Maximum stroke: 150mm
3. Test clip width: 170mm
4.Speed: (65±5) cpm
5. Counter: six-digit LCD display, 0 —— 999.999
6. Volume: (60X30X40) cm
7. Weight: about 50kg
8. Power supply: AC220V 50Hz
