The fire retardant wood stack method combustion test device is developed based on GA/T42.1 standard. The MDF-1 type is designed to test the combustion quality loss rate and flame burning time of flame-retardant-impregnated wood with a thickness over 20mm, used in production and engineering, under specified conditions.

Application

This standard is applicable to testing the mass loss rate and flaming combustion time of various types of wood used in production and engineering, with a thickness of 20 mm or more, after flame-retardant impregnation treatment, under specified combustion conditions.

Standards

GB/T 17658-2018: Test of burning behavior for flame retardant treated wood—Method of test for fire propagation

GA/T 42.2-92: Test method for fire propagation of flame-retardant treated wood (Fire tube method)

ISO 834-1:1999: Fire-resistance tests—Elements of building construction—Part 1: General requirements

EN 1363-1:2012: Fire resistance tests—Part 1: General requirements

Parameters

Features

Sheet metal spray paint treatment, aesthetically pleasing and corrosion-resistant

Heat-resistant glass door for easy observation of internal test conditions

Internal fixtures are all made of stainless steel

Power switch for supplying or cutting off power

Electronic ignition

Infinitely adjustable ignition time, digital display of sample burning time

Burner applies flame to the test specimen for 3 minutes

Temperature at the top opening of the flame protection cover: (310 ± 10) ℃

Flow meter indicates gas flow rate

Gas flow meter: Flow range (0.025-0.25) m³/h

Digital timer: 0-24 min, 1s increment

Ignition time of the burner to the sample is 3 minutes

Flame height approximately 250mm, temperature (310 ± 10) ℃

The burner consists of a 50mm diameter nozzle, regulating valve, and shut-off valve

Thermocouple: 3mm outer diameter nickel-chromium-nickel-silicon armored thermocouple, accuracy class II

Working conditions:

1. Ambient temperature: room temperature —— 35oC

2. Ambient humidity: ≤70%

3. working voltage: AC 220±10V

4. gas source: natural gas, liquefied petroleum gas

5. timing accuracy: 3min±GA/T 42.1 Flame retardant wood burning performance test method wood stack method 0.1s

6. temperature error: 310oC≤±10oC

Specimen Preparation

1. The specimen size is 76mm×13mm×13mm, the cutting error is ±1mm, and the surface is required to be smooth and flat. Three sets of 24 pieces were prepared for each test piece.

2. The specimen is cut 0.6mm away from the longitudinal end of the wood, less than 1m long wood, and cut from the middle to both sides.

3. the specimen cut from the upper and lower sides of the width of the wood along the thickness direction parallel cut 13mm×13mm test piece two layers, and then cut 76mm along the length direction of the test piece, the remaining center part is not sampled.

4. before the test, the specimen must be at a temperature of 23±2oC, relative humidity (50±5) % of the condition, so that its quality is constant. The determination condition is the interval of 24h, the mass change of two weighing before and after each group is not more than 1%.

FAQ

1. What is this product?

A combustion test device for evaluating the fire performance of flame-retardant-treated wood specimens.

2. What is this product used for?

To measure the mass loss and flaming duration of treated wood to ensure compliance with fire safety standards.

3. What is the working principle of this product?

Samples are ignited under controlled conditions, with flame applied for a set duration; mass loss and flame time are recorded to assess fire performance.

4. Why is this product important?

It ensures safety and compliance of flame-retardant wood in construction and engineering applications.

5. What industries is this product suitable for?

Wood manufacturing, construction engineering, fire safety testing labs, and research institutions.
