Flammability Tester

Product Introduction:

The Flame Retardant Paper and Board Burning Tester is a crucial instrument for evaluating the fire safety of paper and cardboard materials treated with flame retardants. This testing is essential across industries like packaging and construction to ensure these materials meet safety regulations. The tester measures how these materials behave when exposed to a controlled flame, quantifying the effectiveness of flame retardant treatments.

Common test methods include vertical and horizontal burning tests. In the vertical test, the paper is ignited at the bottom, and flame propagation is observed. The horizontal test involves igniting an edge of the paper to assess flame spread. These tests measure parameters like afterflame time, char length, and burning rate.

Compliance with standards like UL and ASTM is vital. This testing helps manufacturers ensure their products resist or slow down combustion, reducing fire hazards in various applications, from packaging for sensitive goods to construction materials requiring specific fire ratings. The results are key for quality control and ensuring consumer safety.

Technical parameters:

1. Ambient temperature :-10℃——30℃

2. Relative humidity :{<}85%

3. Power supply voltage and power :220V 10% 50HZ power less than 100W

4. MCU control, digital display automatic timing

5. Manual ignition Bunsen burner on the style flame time 12s, accuracy is 0.01s

6. Afterflame, afterglow time: maximum 0-99M99S

7. The inner diameter of Bunsen burner is 10mm and 0.2mm

8. The Bunsen burner can be tilted in the range of 0-45° (8 gears per 5° gear)

9. Bunsen burner blue flame height :15mm-175mm can be adjusted, equipped with flame height scale

10. Automatic ignition time of Bunsen burner: arbitrary setting

11. Digital display continued flame, burning flame time

12. Gas source: liquefied propane purity {>}95%

13. Appearance size :670x300x800mm

14. Style size :210mmx70mm

15. Weight of the instrument :40kg
