Mercury Lamp Solar Aging Tester
Description:
It is used in various types of textiles to accelerate the aging of mercury lamps under simulated sunlight.
Standard model fitted with 500 watt mercury blended tungs...
Category：Color Fastness Tester
Introduction
Description:
It is used in various types of textiles to accelerate the aging of mercury lamps under simulated sunlight.
Standard model fitted with 500 watt mercury blended tungsten lamp, pre-settable timer and time elapsed counter. Can be fitted with type C & D sample holders within which humidity can be controlled using saturated salts. Rapid Light Fastness Tester.
Rapid fade model fitted with 400 watt mercury tungsten high power lamp with transformer, pre-settable timer and time elapsed counter. Can be fitted with type D sample holders.
Characteristics:
1. LCD touch screen display
2. Adopting the German Osram mercury lamp
Standards:
BS 1006 UK/TN
Technical Parameters:
| Light source | MBTL (mercury tungsten lamp) 500W[4,8] |
| Lamp life | 5000 hours[4,8] |
| Operating temperature | Ambient to 50 °C[4] Control method: Water circulation + ambient air[4] |
| Humidity control | 50-60% RH (auto-regulated)[16,17] |
| Sample holder | Stainless steel clip[19,21] Sample size: 100 × 50 mm[4,23] |
| Water system | Stainless steel tank[25,26] Independent circulating pump[29] |
| Exposure area | 1800 cm²[4,23] |
| Lamp-sample distance | 200 ± 5 cm[4,34] |
| Power supply | 230V AC 50Hz (1-phase)[37,38] |
| Energy consumption | 0.75 kWh [39,41] |
| Dimensions | 500 × 550 × 700 mm[4,43] |
