Molten Metal Splash Impact Tester
Category：Flammability Tester
Introduction
Product Introduction：
Projections of molten metal drops at a point on a vertical oriented test specimen and measurement of the number of the drops required to cause a 40 K temperature rise in a sensor behind the specimen.
Features：
Drop guide to collect the drops and to guide them towards the vertically oriented test specimen.
Senor for measuring the temperature linked to a recording device.
Holding frame and counterweights for the test specimen.
Motor speed can be adjust so that the steel rod is fed at the rate of (10 f 1) g/mm.
Needle valves adjust the O2 and acetylene flow rate.
LCD Screen display and control the motor speed.
Standard：
AQ 6103 ,ISO 9150:1988 , CSN EN 348:1992 ,GB 8965.2:2009. GB/T 17599:1998
Technical Parameters：
| Item | Value |
|---|---|
| Size | 700mm (W) X 850mm (H) X 500mm (D) |
| Weight | 42kg |
| Installation requirements | 220V, 50HZ, 5A |
| Environmental Requirements | Temperature (20+2)degree C, Humidity (65+5)% |
| Gas requirements | oxygen, acetylene |
