Multifunctional Electronic Tensile Tester
Category：Fabric & Textile Tester
Introduction
The system comprises a programmable controller, touchscreen, force sensor, transmission mechanism, and onboard printer. It features Chinese and English menu displays for interactive parameter configuration of automated testing. Production units and batch numbers can be freely entered for user-friendly operation.
A three-level password system ensures secure information protection. Features include: – Product specification settings – Test pressure value configuration – Hold time adjustment – Print settings – Testing execution – Starting position calibration – Time calibration – Calibration verification Onboard printer outputs test data. Touchscreen provides real-time display of test force values, hold times, and other metrics. Printer outputs test data and results. Suitable for testing various products.
Application
Primarily used to determine the tensile properties and fracture strength values of various materials, it serves as one of the key methods for assessing material strength.
Standards
(1) GB/T 16491-2022 — Electronic Universal Testing Machine
(2) ISO 7500-1 — Metallic materials — Verification of static uniaxial testing machines
(3) ASTM E4 — Standard Practices for Force Verification of Testing Machines
(4) ASTM D638 — Tensile Properties of Plastics
(5) ISO 527 — Plastics — Determination of tensile properties
Parameters
| Parameter | Specification |
| Operation Interface | Simplified Chinese / English |
| Programmable Controller | PLC + ARM |
| Touch Screen | 7-inch, K600+ core, dot-matrix 65-color, 800*480 resolution |
| Tension Output Range | 1～1000N, calibration error ≤ ±0.1% of reading |
| Test Duration | 0.1s～99.9min, error ≤ ±0.1s |
| Running Speed | 1～300mm/min |
| Ambient Temperature | 25±15℃ |
| Test Stroke | 500mm |
| Net Weight | 25kg |
| Dimension | 430×250×850 (mm) |
| Power Supply Voltage | AC85V～265V/50Hz (self-adaptive wide voltage) |
| Total Machine Power | 500W |
| Sensor | High-precision force sensor |
| Force Measuring Mechanism | Built-in |
| Printer | Built-in dot-matrix printer |
| Test Mode | Tensile or Compression |
Features
(1) Integrated PLC + ARM control for stable and precise operation.
(2) Touchscreen human-machine interface for intuitive parameter setup.
(3) High-precision force measurement with excellent repeatability.
(4) Wide-range speed control for different material requirements.
(5) Real-time display of force and hold time during testing.
(6) Built-in printer for immediate data output and record keeping.
(7) Three-level password protection for data security.
(8) Supports both tensile and compression test modes.
(9) Compact bench-top design suitable for laboratory environments.
FAQ
(1) What is this product?
It is a programmable electronic tensile testing machine used to measure tensile and compression properties of materials.
(2) What is this product used for?
You use it to determine tensile strength, fracture force, and compression performance for quality control and research.
(3) What is the working principle of this product?
The machine drives the specimen at a controlled speed while the force sensor continuously measures the applied load until the preset condition or failure occurs.
(4) Why is this product important?
Accurate tensile testing helps you verify material strength, ensure product quality, and meet international testing standards.
(5) What industries is this product suitable for?
It is suitable for plastics, packaging, medical devices, textiles, rubber, research laboratories, and quality inspection agencies.
