Geomembrane Tester

A Multilayer Geotextile Single-Layer Thickness Tester is a specialized precision instrument used to measure the individual layer thickness within a multilayer geotextile product under specified pressures.

Unlike a standard geosynthetics thickness tester that measures the overall thickness of a composite product, this instrument is designed to isolate and quantify the thickness of each constituent layer. This is crucial for quality control, ensuring proper material composition, and verifying design specifications for complex geosynthetic systems used in civil engineering applications like landfills, road construction, and erosion control.

Scope of application:

The multi-layer sample is mechanically separated and the thickness of each single layer of the sample is measured under the specified pressure

Meet the standard:

GB/T17598-1998. etc.

Instrument features:

Thickened upper and lower rectangular plate, can withstand large pressure without deformation;

Straight sliding copper sleeve, smooth plate movement, to ensure the parallelism of the upper and lower plates;

Hand-operated lifting mechanism, maximum force value 1.8T, stable force value, can be fixed on any stroke,

Digital display measuring calipers for easy reading.

Technical parameters:

Rectangular plate thickness 30mm

Travel 0——120mm

Maximum pressure 300kPa

Measuring range 0——200mm

Index value 0.01mm

Point wire φ0.05mm, length 20mm

Isolation plate thickness 2mm

Dimensions: 430*210*510mm

It weighs about 80kg

Standard configuration:

1. One host

2. 1 vernier caliper

3. 1 special wrench

4. Product packing list 1 copy

5. 1 copy of product manual

6. Product tag certificate 1 copy
