Nail Bed Flammable Tester
Category：Flammability Tester
Introduction
The Nail Bed Flammable Tester is used as test fixture in the flammability test of solid and soft toys. Place the prepared sample in a draft-free area that can be ventilated and cleared after each test. A specified ignition source is acted on the sample until ignition occurs. Observe the combustion state of sample and assess its flammability.
Applications
The tester is designed for determining the flammability of cloth toys and plush toys, used in the detection of flammability of flammable hair, and recording the burning time, to make a assessment whether the flammability of the burning part meet the requirement of standards.
Standards
16CFR1510：Requirements for Rattles
ASTM F963-4.6.2：Standard Consumer Safety Specification for Toy Safety
Technical Parameters
| Items | Parameters | |
| Socket Wrench Screw 1 | Material | Stainless Steel |
| Dimension | # 10-32×0.38inches(LG) | |
| Quantity | 9 | |
| Apart from the edge | 0.31inches(7.8mm) | |
| Screw spacing | 1.25inches(31.75mm) | |
| Nail 2 | Material | Stainless Steel |
| Dimension | # 8d×2.50 inches(LG) | |
| Quantity | 64 | |
| Apart from the edge | 0.62inches(15.7mm) | |
| Screw spacing | 4.69 inches(119mm) | |
| Up plate-stainless steel plate 3 | 0.12×10.12×10.12inches(3×257×257mm)(LG) | |
| Bottom plate-stainless steel plate 4 | 0.25×10.00×10.06inches(6.35×254×255.5mm)(LG) | |
| Outside dimension | Approx. 254×254mm(1×1inches) | |
Features
1. High Precision: Constructed from corrosion-resistant and wear-resistant materials such as stainless steel, ensuring the equipment’s precision and durability.
2. Easy Operation: User-friendly design, simple and convenient operation, easy maintenance and upkeep.
3. Data Recording: Equipped with an advanced data recording system, capable of recording and analyzing test data in real time, improving testing efficiency.
Accessoriess
One bed of nails burner; two standard burning candles.
Test Procedures
1. Place the sample on the equipment and measure its length;
2. Use a candle with a flame height of 16 mm to ignite the sample for 5 seconds, remove the flame, and then allow it to burn for another 5 seconds or until it reaches the other end of the main shaft. Calculate the burning rate.
