Textile Far Infrared Radiation Temperature Rise Tester
Category：textile Functional tester
Introduction
I. Instrument Application
Used for various textile products including fibers, yarns, fabrics, nonwovens and their derivatives to determine far infrared properties through temperature rise tests.
II. Test Principle
After irradiating specimens with a constant-intensity far infrared radiation source for specified duration, measure the temperature elevation on the specimen’s test surface.
III. Compliance Standards
GB/T30127 4.2 (Far Infrared Radiation Temperature Rise Test) and other relevant standards.
IV. Technical Parameters
| Parameter Item | Parameter Value |
|---|---|
| Specimen Holder | 500mm distance from radiation source to specimen surface |
| Radiation Source | Main wavelength 5μm~14μm, radiation power 150W |
| Specimen Irradiation Area | φ60~φ80mm |
| Temperature Range & Accuracy | 15℃~50℃, ±0.1℃ precision, ≤1s response time |
| Specimen Types | Yarns: ≥60mm square metal frame Fibers: φ60mm×30mm open cylindrical container Fabrics: φ≥60mm |
V. Product Features
Thermal insulation baffle: Front-mounted heat shield improves test accuracy and reproducibility
Fully automatic measurement: Tests initiate automatically when lid is closed
Equipped with Matsushita (Panasonic) power meter for real-time power monitoring
Uses Omega sensors and transmitters
Three specialized specimen holders (yarn/fiber/fabric)
Optical modulation technology eliminates environmental radiation interference
