Thermal Insulation Material Flame Retardant Test Furnace
Category：Material Combustion Tester
Introduction
The Thermal Insulation Material Flame Retardant Test Furnace is a performance testing device designed for evaluating the flame retardancy of thermal insulation materials. Equipped with an intelligent touchscreen control system, it provides convenient and user-friendly operation. This instrument is widely used across industries such as construction, transportation, light industry, electronics, and energy, making it a practical tool for industrial testing.
Applications
This furnace is suitable for testing the flame retardancy of a variety of thermal insulation materials, including:
Thermal insulation boards and panels for walls, ceilings, and floors
Pipe insulation materials (glass wool, rock wool, polyurethane foam)
HVAC duct insulation layers
Foam insulation sheets for electrical cabinets and energy storage devices
Mineral wool and composite insulation products used in industrial equipment
Standards
DB11/381-2016 Appendix D – Method for Testing Flame Retardancy of Thermal Insulation Materials
Technical Parameters
| Parameter | Specification |
|---|---|
| Ambient Temperature | 20 °C – 40 °C |
| Power Supply | 220 V ±10 %, 50 Hz, 2.5 kW |
| Weight | 35 kg |
| Data Acquisition Interval | <2 s |
| Heating Rate | 5 °C/min |
| Test Duration | 24 h |
| Test Temperature Range | Room temperature – 400 °C |
| Thermocouple Type | K-type armored thermocouple |
| Temperature Measurement Range | 0 – 1000 °C |
Advantages
Intelligent touchscreen control for easy and fast operation
Accurate and rapid data acquisition with high repeatability
Comprehensive safety features to minimize operational risks
Wide applicability for multiple thermal insulation materials
Strong after-sales support with readily available spare parts and timely technical assistance
Compliance with the latest industry standards for up-to-date testing requirements
FAQ
What is this product?
It is a flame retardancy test furnace for thermal insulation materials.
What is it used for?
Used to evaluate and record the flame retardant properties of insulation materials under controlled temperature conditions.
What types of this product exist?
Standard tabletop or benchtop flame retardancy furnaces for thermal insulation materials.
What industry problems can it solve?
Ensures insulation materials meet safety and flame retardancy standards, helping manufacturers and regulators maintain compliance.
How is it operated?
Operated via an intelligent touchscreen, users set test parameters, start the furnace, and monitor temperature and data acquisition automatically.
