Coating Thickness Gauge
Category：Other
Introduction
Product Introduction & Applications
The Coating Thickness Gauge is a high-precision instrument designed for measuring the thickness of films, foils, paper, sheets, non-woven materials, and a wide range of industrial substrates. The system is engineered with an automatic lifting measuring head to eliminate human error, ensuring stable, accurate, and repeatable results.
With both automatic and manual measurement modes, custom measurement pressure, optional automatic injection, and real-time statistical analysis, the gauge meets the needs of laboratories, R&D centers, and industrial quality inspection departments.
Basic Applications
Plastic film, wafer, diaphragm paper, cardboard
Metal foil, silicon sheets, thin metal plates
Solid electrical insulating materials
Non-woven products (diapers, sanitary napkins, hygiene materials)
Extended Applications (with optional accessories or customization)
Extended measuring range up to 5 mm or 10 mm
Curved measuring head for special-shaped surfaces
Customized contact area, pressure, platform size, or measuring diameter
This device is ideal for packaging, electronics, new materials, hygiene products, paper manufacturing, and industrial coating industries.
Standards Compliance
The Coating Thickness Gauge complies with a wide range of international standards, ensuring global reliability and test repeatability:
GB/T 6672, GB/T 451.3, GB/T 6547
ISO 4593, ISO 534, ISO 3034
ASTM D374, ASTM D1777
TAPPI T411
JIS K6250, JIS K6783, JIS Z1702
BS 3983, BS 4817
Technical Specifications
| Category | Specification |
|---|---|
| Measuring Range | 0–2 mm (standard) / 0–5 mm or 0–10 mm (optional) |
| Resolution | 0.1 μm |
| Measuring Pressure | 0.5–1.0 N |
| Measuring Diameter | Φ3 mm – Φ10 mm (optional, customizable) |
| Platform Area | 520 × 390 mm (customizable) |
| Automatic Injection Speed | 0.1–99.9 mm/s |
| Power Supply | AC 220 V, 50 Hz |
| Overall Dimensions | 620(L) × 415(W) × 350(H) mm |
| Net Weight | 40 kg |
| Customization | Other measuring ranges, pressure, fixtures, or heads available |
FAQ
1. What materials can this Coating Thickness Gauge measure?
It can test films, foils, paper, cardboard, silicon sheets, metal sheets, electrical insulating materials, and non-woven hygiene products. Extended applications allow measurement of thicker films and curved surfaces.
2. How does the automatic lifting system improve accuracy?
The measuring head automatically rises and falls during testing, preventing human-induced force variation and ensuring consistent measurement pressure and repeatable results.
3. Does the instrument support data storage and printing?
Yes. The system displays real-time data, performs automatic statistical analysis, and supports printing and USB data export.
4. Can the device be customized?
Absolutely. Measuring pressure, diameter, platform size, head type, and measuring range can all be customized to meet specific industry needs.
5. What standards does the gauge comply with?
It meets GB, ISO, ASTM, JIS, BS, and TAPPI standards, making it suitable for international testing and global product certification.
