The Mechanical Load Testing Machine for Photovoltaic Modules is designed to evaluate the structural strength and durability of PV modules under simulated environmental loads. It replicates snow, wind, hail, and debris impact conditions by applying precise forward, reverse, and dynamic mechanical loads, ensuring modules meet global reliability and certification requirements.

This machine is essential for PV module manufacturers, testing laboratories, and R&D teams seeking to verify mechanical performance and prevent field failures.

Applications

The system is widely used for:

PV module design qualification and type approval

Structural durability testing under snow and wind loads

Dynamic fatigue testing simulating hail and debris impacts

Quality control and batch testing during PV manufacturing

R&D for framed, frameless, and flexible PV modules

It helps detect glass cracks, cell breakage, frame deformation, and lamination issues before field deployment.

Applicable Standards

The machine is fully compliant with international standards:

IEC 61215 – Terrestrial PV Modules: Design Qualification and Type Approval

IEC 61646 – Thin-Film PV Modules: Design Qualification and Type Approval

IEC 62782 – Dynamic Mechanical Load Testing for PV Modules

UL 1703 – Flat-Plate PV Modules and Panels

CE Certification – Conformité Européenne

Compliance ensures globally recognized, reliable, and repeatable testing results.

Product Advantages

Multi-Standard Compliance

5,400 Pa forward / 2,400 Pa reverse loading replicates snow and wind loads per IEC 62782.

1,000 Pa dynamic load simulates 1,000-cycle fatigue for hail/debris impact.

Ultra-Precise Control

0.1N force feedback ensures ±5% pressure accuracy.

7+3s cycle timing mimics real-world pulsating wind loads.

Automated Testing

Programmable cycle count (1–99,999) with auto-stop at failure.

AI-powered failure detection correlates EL imaging with real-time crack analysis.

Safety First

Emergency shutoff with dual redundant safety circuits.

Overload protection: 6,000 Pa maximum pressure cutoff.

Modular & Flexible Design

Quick-change fixtures adapt to framed, frameless, and flexible PV modules.

Expandable test area up to 3.0 m × 2.0 m for large-format modules.

Product Features

Dual-mode operation: static and dynamic load testing with auto-switching.

10” touchscreen HMI with preloaded IEC/UL test sequences and customizable profiles.

Remote monitoring via Wi-Fi/Ethernet with SMS/email alerts.

Self-calibrating system with auto-tare and linearity checks.

Rust-resistant frame: 304 stainless steel with epoxy coating.

Accessories Included:

PV module clamping fixtures and load distribution pads

LoadTest Pro software license + cloud fatigue analysis access

NIST-traceable pressure gauge, safety harness kit

Spare O-rings, cylinder seals, cleaning solution

Multilingual quick-start guide and compliance certificates

Technical Parameters
