The garment fabric wet adhesion performance tester
Applicable Standards
1. T/CNGA 64-2024: “Test Method for Wet Adhesion of Garments”
2. FZ/T standard (Under review and pending release)
Application Scope
The garment ...
Category：Other
Introduction
Applicable Standards
1. T/CNGA 64-2024: “Test Method for Wet Adhesion of Garments”
2. FZ/T standard (Under review and pending release)
Application Scope
The garment fabric wet adhesion performance tester is used to evaluate the adhesion degree of clothing fabrics to human skin after being soaked in liquid.
Technical Specifications
1. Evaluation system: Four-level wet adhesion performance grading system (Grade 1: Excellent, Grade 4: Poor)
2. Maximum load range: 300g
3. Force measurement range: 0.4%-100% FS
4. Measurement precision: 0.03% FS
5. Testing speed: 1-100mm/min
6. Maximum displacement: 80mm
7. Displacement precision: 10µm
8. Servo motor & driver: Panasonic
9. Dimensions: 545×419×509mm (W×D×H)
10. Power supply: AC 220V ±10%, 400W
11. Net weight: 25kg
