Hair Loss Tester
Category：Other
Introduction
Product Functions and Applications
The Hair Loss Tester is designed to evaluate the hair loss amount of various woven wool blankets. It provides precise and repeatable testing results through its digital counter–based control system.
The instrument allows preset cycle quantities, performs automatic counting, and collects motion signals using a Hall sensor, with results displayed clearly on an LED screen.
It is known for its testing accuracy, operational stability, reliability, and low-noise performance.
When equipped with a 30 mm rubbing head, the tester can also be used for colorfastness-to-rubbing tests on dyed fur materials.
Standards Compliance
FZ/T 60029
FZ/T 61001-2006
FZ/T 6004-2006
GB/T 14254-1993 (with a Φ30 mm rubbing head; Test Method for Color Fastness to Rubbing of Dyed Fur)
Technical Specifications
| Parameter | Specification |
|---|---|
| Brush Direction | Unidirectional |
| Brush Stroke | 270 mm |
| Moving Speed | 26 times/min |
| Brush Test Area | 200 cm² |
| Pressure of Brush Holder | 8.35 ± 5.09×10⁻⁶ Pa |
| Counting Range | 1 – 999,900 times |
| Power Supply | AC 220V ± 10%, 50Hz |
| Net Dimensions | 560 × 360 × 450 mm |
| Packing Dimensions | 640 × 440 × 500 mm |
FAQ
1. What materials can be tested with the Hair Loss Tester?
It is mainly designed for woven wool blankets, but when paired with a Φ30 mm rubbing head, it can test dyed fur for colorfastness.
2. Does the tester support automatic cycle counting?
Yes, it features a digital counter with preset cycle capability and automatic signal collection via a Hall element.
3. How accurate is the test result?
The instrument provides high accuracy and excellent repeatability due to its stable mechanical design and electronic control system.
4. What is the required power supply?
It operates on AC 220V ± 10%, 50Hz.
5. Is the operation noisy?
No, the device is designed to operate with a soft, low-noise sound profile suitable for laboratory environments.
