UV curing light box
Category：Other
Introduction
Product Function & Application
The UV Curing Light Box is designed for rapid curing of adhesives, coatings, inks, encapsulants and UV-sensitive materials. With high-intensity LED UV sources and a fully enclosed curing chamber, it delivers consistent irradiation for laboratory R&D, electronics manufacturing, optics bonding, medical device assembly, and precision industrial production.
Its selectable wavelengths (365 nm, 385 nm, 405 nm) enable compatibility with a wide range of UV-curable chemistries, including acrylics, epoxies, urethanes, and specialty adhesives.
Standards Compliance
ISO 10977 — Light Curing of Adhesives and Coatings
Ensures the curing chamber, wavelength output and intensity control meet international UV curing requirements.
ASTM E3022 — Standard Practice for Measurement of Ultraviolet (UV) Light Systems
Specifies radiometric and photometric measurement accuracy for UV irradiance.
IEC 62471 — Photobiological Safety of Lamps and Lamp Systems
Ensures safe UV exposure levels for operators and defines UV leakage limits.
Product Advantages
1. Professional-Grade UV Curing
High-intensity LED modules provide strong and stable irradiation at 365 nm, 385 nm or 405 nm. Output decay remains below 1% even after 50,000 hours of use, ensuring long-term consistency.
2. Safety-First Design
The fully enclosed curing chamber prevents UV leakage, maintaining UVC levels below 0.1 µW/cm². An interlock system automatically shuts off UV when the door opens.
3. Portable & Flexible
Weighing only 5 kg, the unit is easy to carry between production lines or field environments. It supports 110–240V global voltage, making it suitable for international users.
4. Industrial-Grade Durability
The anodized aluminum housing resists corrosion, chemicals and impact. It performs reliably from –20°C to 60°C, making it suitable for challenging industrial conditions.
5. Energy-Efficient Operation
LED UV curing consumes up to 70% less energy than traditional mercury lamps. Instant on/off capability eliminates warm-up and cool-down time, improving workflow efficiency.
Product Features
LED System
Selectable wavelengths: 365 nm (UVA), 385 nm (UVB), 405 nm (UVC)
90% irradiance uniformity across a 450 × 400 mm curing area.
Control Panel
Digital timer (1–999 seconds) with repeat function
Adjustable power output from 10% to 100%
Safety Systems
Emergency stop button
Overheat protection with auto cooling
Door interlock system to prevent direct exposure
Ergonomic Design
Removable glass window
Adjustable internal shelf (0–50 mm) for curing 3D components
Connectivity
USB port for software upgrades
RS-232 interface for PLC or automation line control
Technical Parameters
| Specification | Details |
|---|---|
| Work Area | 450 mm × 400 mm × 150 mm |
| Wavelength Options | 365 nm / 385 nm / 405 nm |
| Max. Irradiance | 12,000 mW/cm² (adjustable) |
| Power Supply | 100–240V, 50–60Hz |
| Dimensions (W × D × H) | 520 mm × 465 mm × 510 mm |
| Net Weight | 5 kg |
| Operating Conditions | 0–45°C, <85% RH (non-condensing) |
FAQ
1. What types of materials can be cured in this UV light box?
It is compatible with UV-curable adhesives, coatings, inks, encapsulants, resins, and optical bonding materials.
2. Does the UV chamber prevent leakage and protect the operator?
Yes. The fully enclosed design and interlock system ensure UV leakage is below regulatory limits and the lamp shuts off automatically when the door is opened.
3. Can I choose different UV wavelengths for different adhesives?
Yes. The system supports 365 nm, 385 nm, and 405 nm to match various curing chemistries.
4. Does the unit require warm-up time?
No. LED curing technology provides instant on/off operation with consistent output.
5. Can this system be integrated into automated production lines?
Yes. The RS-232 interface supports PLC integration for automated or semi-automated curing workflows.
