Photo fill light box
Category：Other
Introduction
Introduction
The Photo Fill Light Box is a professional-grade lighting solution designed for product photography, videography, and studio shoots. Featuring adjustable bi-color LED panels, high CRI output, and versatile mounting options, it provides uniform, flicker-free illumination for capturing true-to-life colors. Its modular design, portable structure, and energy-efficient operation make it ideal for both studio and location use.
Standards Compliance
CE & FCC Certified — Meets electromagnetic compatibility and safety standards for EU and US markets.
RoHS Compliant — Lead-free construction for environmentally responsible photography.
IEC 60598-1 — Luminaire safety requirements for commercial lighting equipment.
Product Advantages
1. Customizable Illumination
Modular LED panels with adjustable color temperatures from 5,600K (daylight) to 3,200K (tungsten). High CRI ≥95 ensures accurate, natural color reproduction.
2. Versatile Studio Setup
Dual light box design with 1,187 mm × 688 mm illuminated surfaces provides 360° coverage. Adjustable aluminum stands from 1.5–2.2 m enable flexible positioning.
3. Portable Performance
Weighing 55 kg in total, the split design allows easy transport. Tool-free quick-release clamps enable assembly in under 3 minutes.
4. Energy Efficiency
800W maximum power consumption (equivalent to 4,000W traditional tungsten lamps). Flicker-free dimming from 0–100% suitable for 4K/8K video recording.
5. Industrial Durability
Aluminum alloy frame supports up to 50 kg and resists warping. IP20-rated housing provides dust resistance for studio or location use.
Product Features
Lighting System:
Bi-color LED panels, 3,200K–5,600K adjustable via control box
Barn doors included for precise light shaping
Control Interface:
4-channel dimmer with memory presets
DMX512 compatibility for professional lighting integration
Safety Systems:
Overheat protection with auto-shutoff at 60°C
Residual current device (RCD) for operator safety
Mounting Options:
Baby pin adapters compatible with Bowens/Elinchrom modifiers
360° swivel brackets for overhead or side lighting
Connectivity:
2 × 3 m (10 ft) power cables with locking connectors
Optional V-Mount battery plate for mobile shoots
Accessories & Options:
Softboxes (60×60 cm, 80×80 cm), grids, beauty dishes, snoots
Wireless remote control and smartphone app (optional module)
V-Mount batteries, extension cables, replacement diffusion panels, lens cleaning kit
Technical Parameters
| Specification | Details |
|---|---|
| Light Box Dimensions | 1,302 mm × 803 mm × 100 mm |
| Illuminated Area | 1,187 mm × 688 mm |
| Color Temperature | 3,200K–5,600K (adjustable) |
| CRI (Ra) | ≥95 |
| Power Supply | 220V/50Hz (110V optional) |
| Max. Power Consumption | 800W (400W per lamp) |
| Operating Conditions | 0–40°C, <80% RH (non-condensing) |
| Frame Height | 1.5–2.2 m (adjustable) |
FAQ
1. Can I adjust the color temperature of the light panels?
Yes. The bi-color LED panels are adjustable from 3,200K (tungsten) to 5,600K (daylight) for accurate color rendering.
2. How large is the illuminated surface area?
The dual light box design provides 1,187 mm × 688 mm (46.7” × 27.1”) of uniform lighting.
3. Is the system portable for location shoots?
Yes. The split design and tool-free assembly allow rapid setup and easy transport, even in vehicles.
4. Can this light box be dimmed for video work?
Yes. It supports 0–100% flicker-free dimming suitable for 4K/8K videography.
5. What safety features are included?
Overheat protection, auto-shutoff, and residual current device (RCD) ensure operator safety during use.
