Pipe drop hammer impact testing machine
Category：Other
Introduction
Product Introduction
The Pipe Drop Hammer Impact Testing Machine (Model G-1) is an automatic instrument designed to evaluate the impact resistance of pipes, hard plastic sheets, profiles, and automotive parts. The machine uses a precision-controlled drop hammer to simulate external impact forces, with intuitive touch screen display of lifting height. It complies fully with the standard ZBN72026 “Technical Conditions of Drop Hammer Impact Testing Machine” and allows accurate and repeatable impact testing across a wide range of materials and pipe types.
Application Scope
Suitable for testing impact resistance of:
PVC-U water pipes, sewage pipes, low-pressure water pipes
Core layer foam pipes, double-wall bellows
PE water pipes, communication pipes
Hard plastic sheets, profiles, and automotive components
Widely used in plastic product manufacturing, pipeline quality control, and material R&D laboratories.
Applicable Standards
ISO 3127: Plastics pipes – Determination of impact resistance
ASTM D2444: Standard Test Method for Impact Resistance of Plastic Pipe and Fittings
DIN-EN 744: Plastics piping systems for water supply
BS-EN 1411: Thermoplastics pipes – Determination of impact strength
Product Advantages
High Precision & Reliability: Uses scratch-resistant steel hammer and imported precision components for durability and accurate impact measurement.
Intelligent Automation: PLC-controlled automatic suction, zeroing, lifting, and drop functions prevent secondary impacts and ensure repeatability.
Real-Time Monitoring: Touchscreen display shows instant impact height, speed, and operational status.
Safety & Convenience: Power failure protection, small footprint, easy installation, and labor-saving operation.
Compliance & Speed: Meets GBT14152-2001 requirements for low-temperature sample testing (0°C, 20 seconds from removal to impact).
Technical Parameters
| Parameter | Specification |
|---|---|
| Maximum Impact Energy | 300 J |
| Impact Height Range | 50 mm ±2 mm – 2000 mm ±2 mm |
| Impact Height Accuracy | ±2 mm |
| Energy Loss | <0.25% |
| Repeated Positioning Error | <±1 mm |
| Applicable Pipe Diameter | 20 mm – 400 mm |
| Power Source | AC 220V ±15%, 50Hz, 500W (single-phase, three-wire) |
| Machine Dimensions (Type A) | 1280 × 600 × 3950 mm |
Accessories & Optional Modules
Touchscreen HMI with impact height display and speed monitoring
PLC control panel with automated test sequences
Power failure protection module
Optional data acquisition software for recording impact energy and test results
