Automotive Sealing Strip Abrasion Tester
Category：Interior Material Tester
Introduction
The Automotive Sealing Strip Abrasion Tester is a newly developed instrument designed for testing the wear resistance of various automotive sealing strips. It is widely used in vehicle manufacturers and their suppliers to evaluate flocked or coated guide channel seals, door frame seals, door seals, and trunk seals. The tester accurately simulates real-world wear conditions to ensure product durability and quality compliance.
Application
(1) Abrasion testing of automotive flocked and coated guide channel seals
(2) Durability evaluation of door frame sealing strips, door seals, and trunk seals
(3) Quality control in automotive production and component manufacturing
(4) Research and development for new sealing strip materials
Standards
(1) Volkswagen Technical Standard TL 52057 / TL 52417 – PV3313 Abrasion Test
(2) Volkswagen Technical Standard TL 52641 – PV3366 Abrasion Test
(3) China Automotive Industry Standard QC/T 711-2004 – Abrasion Test for Flocked Seals
(4) National Standard GB/T 21282-2007 – Passenger Vehicle Rubber & Plastic Seals
(5) Other relevant domestic and international automotive seal abrasion standards
Parameters
| Parameter | Specification |
|---|---|
| Type | 6-hammer electric |
| Sample | Various automotive sealing strips |
| Load | 250 g, 325 g, 500 g, 1000 g, 3000 g (customizable per standard) |
| Abrasion Stroke | 0–160 mm |
| Adjustable Abrasion Head Height | 0–50 mm |
| Abrasion Speed | 0–90 cycles/min |
| Counter Range | 0–999,999 cycles |
Features
(1) Vertical friction head support with weights directly mounted on the head, ensuring precise load application (same as German counterparts)
(2) Fixed sample platform with slotted plate; elbow clamps secure the sample for consistent testing
(3) Adjustable stroke and head height to accommodate different sealing strip types
(4) User-friendly counter and speed control for repeatable results
(5) High-quality construction for long-term durability and low maintenance
Accessories
(1) Set of standard friction heads
(2) Set of calibration weights
(3) Sample holding plates with elbow clamps
(4) Counter and control panel
Maintenance Information
(1) Regularly check friction heads and weights for wear or damage.
(2) Clean the sample platform and clamps after each test.
(3) Ensure the counter and speed control mechanisms are functioning properly.
(4) Lubricate moving parts as recommended by the manufacturer.
(5) Calibrate the load and stroke periodically to maintain test accuracy.
FAQ
What is this product?
It is an Automotive Sealing Strip Abrasion Tester for evaluating the wear resistance of various automotive seals.
What is it used for?
To measure the durability and wear resistance of door seals, trunk seals, and flocked or coated guide channel seals.
Why is it important?
Ensures sealing strips meet industry durability standards and maintain their function over time.
Which industries is it suitable for?
Automotive manufacturing, automotive component suppliers, material testing labs.
What are the similar products?
Flock abrasion testers, door seal abrasion testers, trunk seal wear testers.
