Coil Spring Torsion Performance Testing Machine
Category：Torsion Testing Machine
Introduction
The Coil Spring Torsion Performance Testing Machine is mainly used for testing the torsion torque, torsion angle, and torsional mechanical properties of coil springs, automotive torsion springs, spiral springs, and other elastic components.
Application
The Coil Spring Torsional Mechanical Performance Testing Machine is designed for testing the torsion angle, torque, and other mechanical properties of automotive torsion springs, spiral springs, and other elastic components.The machine can measure the torque of springs at a specified rotation angle or measure the rotation angle under a specified torque. It can also be used for torsion performance testing of other elastic components and friction mechanisms.
Applicable Standards
GB/T 10128 — Metallic Materials — Torsion Test Method at Room Temperature
GB/T 1239 — Cold Coiled Helical Springs Technical Requirements
JB/T 7796-2005 — Spring Tension and Compression Testing Machine (Related spring testing reference)
GB/T 2611 — General Requirements for Testing Machines
GB/T 16825.1 — Verification of Static Uniaxial Testing Machines
ISO 7800 — Metallic Materials — Wire — Simple Torsion Test
Main Technical Specifications
| Item | Technical Parameters |
|---|---|
| Main Specification Range | 10 N·m / 20 N·m / 50 N·m / 100 N·m |
| Minimum Torque Angle Reading Value | 0.1° |
| Specimen Height | 120 mm |
| Test Space | 200 mm |
| Torque Plate Diameter | 120 mm |
| Equipment Dimensions | 510 × 300 × 480 mm |
| Equipment Weight | 120 kg |
| Power Supply | 220 V, 50 Hz |
Main Features
Specially designed for torsion performance testing of coil springs and elastic components.
Measures torque and torsion angle accurately.
Supports torque measurement at a specified angle and angle measurement under a specified torque.
High-precision torque measurement system ensures reliable test results.
Suitable for automotive torsion springs, spiral springs, and other elastic parts.
Compact structure, simple operation, and stable performance.
Suitable for quality inspection, product development, and laboratory testing.
