Filter Dynamic Cycling Tester
Category：Filter Cartridge Filtration Tester
Introduction
Filter element dynamic cycling test bench is mainly used to test the chemical element precipitation characteristics of filter element under long-term dynamic cycling. It adopts touch screen operation mode, combined with PLC control, according to the setting line, and can analyze and judge the abnormal state in the test process and send out alarm information. Manual interval sampling and analysis.
Applications
Filter Dynamic Cycling Tester Mainly used for performance testing of filter elements (such as hydraulic oil filter elements, fluid filtration filter elements, etc.):
1. Evaluating the chemical element precipitation characteristics of filter elements under long-term dynamic cyclic conditions;
2. Testing the durability of filter elements under repeated dynamic stress cycles and predicting their fatigue life;
3. Assisting in the quality inspection, performance verification, and research and development improvement of filter elements.
Standards
(1) ISO 23840 — Hydraulic fluid power — Filters — Evaluation of filter performance using multipass test.
(2) JB/T 7857 — Performance test of hydraulic filter elements.
(3) ISO 2942 — Hydraulic fluid power — Filter elements — Verification of fabrication integrity.
(4) GB/T 14041.1-1993 — Hydraulic filter elements — Structural integrity test methods.
(5) ISO 4003 — Permeable sintered metal materials — Determination of fluid permeability.
(6) GB/T 5249-1985 — Permeable sintered metal materials — Bubble test method for pore size determination.
(7) QC/T 794-2007 — Filter paper for internal combustion engines.
Technical Parameters
| No. | Technical Indicators | Specifications |
|---|---|---|
| 1 | Test medium | Water containing boron, and containing lithium hydroxide |
| 2 | Test flow | 2-10 m³/h (working point: 5.7) |
| 3 | Rated pressure | 0.8 MPa |
| 4 | Test cartridge differential pressure | 0.4 MPa |
| 5 | Maximum working temperature | 80°C |
| 6 | Test tank volume | 2000L |
| 7 | Maximum cartridge size | 2.5 inches × 60cm (diameter × height cm), with a set of equipment |
| 8 | Test bench power | 22kW |
| 9 | Test bench power supply | Three-phase five-wire AC380V / 50Hz |
Features
1. Specialized Functions: It can test the chemical element precipitation characteristics of filter elements under long-term dynamic cycling, and simultaneously evaluate the durability of filter elements under repeated dynamic stress cycling and predict fatigue life.
2. Intelligent Control: Utilizing touchscreen operation + PLC control, it can automatically identify and alarm abnormal states during the test process, offering convenient operation and stable performance.
3. Comprehensive System Configuration: Includes a circulation system (variable frequency pump set, temperature control/stirring components), a real-time temperature control system (temperature control accuracy ±2℃), and an industrial-grade electrical system, with clearly defined functional modules.
4. Lightweight Structure: The test bench frame is made of high-strength industrial aluminum profiles, combining the advantages of light weight, high strength, and aesthetic appearance.
Accessoriess
1. Core Functional Components:
Circulation System: Variable frequency pump set, test oil tank, temperature control system (including 2 independent heaters), bypass pressure regulator, stirrer;
Real-time Temperature Control System: Heating device, temperature sensor;
Electrical Control System: PLC module, touch screen, industrial-grade hardware components;
2. Auxiliary Components:
Manual sampling assembly;
High-strength industrial aluminum profile test bench frame;
Piping, joints, seals, and other connecting components.
FAQ
1.What is this product?
Filter Dynamic Cycling Tester is a test bench designed to evaluate filter element performance under long-term dynamic cyclic operating conditions.
2.What is this product used for?
You use it to assess chemical element precipitation behavior, durability, and fatigue life of filter elements during repeated dynamic cycles.
3.What is the working principle of this product?
The system circulates a specified test medium through the filter element under controlled flow, pressure, and temperature cycles while monitoring operating stability and abnormal conditions.
4.Why is this product important?
It helps you verify filter element reliability, predict service life, and improve product design for long-term operation.
5.What industries is this product suitable for?
Hydraulic and fluid filtration manufacturing, energy and chemical industries, research institutes, and third-party testing laboratories.
