Spray Aerosol Enclosed Space Tester
Category：Other
Introduction
Aerosol spray enclosed space test instrument is used to assess flammability of the aerosol in a closed or restricted space. It is in line with the United Nations “on the Recommendations on the Transport of Dangerous Goods • Manual of Tests and Criteria” 31.5 enclosed space ignition test and “dangerous sprays enclosed space ignition test methods.”
Instrument consists of two parts, the display control section, the detection system composed of a cylindrical container body detection system, built-in light sensors and high-precision thermocouple sensor automatically determine whether knocking occurred. The operator can monitor the entire testing process through the display control section LCD screen.
Standards
(1)GB/T 21631-2008
(2)GAT536
(3)NY/T 1860
Technical parameters
|
Operating Environment |
(5～40)℃, <85%RH |
|
Ambient Temperature Measurement Range |
-10℃～+60℃ |
|
Ambient Temperature Measurement Accuracy |
±0.5℃ |
|
Ambient Humidity Measurement Range |
5%RH～95%RH |
|
Ambient Humidity Measurement Accuracy |
±5.0%RH |
|
Combustion Detection Response Time |
≤6ms |
|
Pressure Measurement (Differential Pressure) Range |
-5 kPa ~ 5kPa |
|
Pressure Measurement Accuracy |
±0.1%FS |
|
Timing Display Resolution |
0.1s |
|
Ignition Flame |
Compliance with the standard candle flame, adjust the height of the cushion column 20mm / a |
|
Cylindrical Vessel Dimensions |
Ф600mm × 720mm |
|
Positioning of Aerosol Tanks |
Aerosol canisters can be automatically turned over |
|
Dimensions of Compatible Misting Tanks |
Height (120 ~ 400) mm, diameter (30 ~ 80) mm |
|
Distance of the Cylindrical Vessel from the Nozzles of Misting Tanks |
(25 ~ 100) mm adjustable |
|
Liquid Accumulation Tray |
accumulation of spray cans sprayed the remnants of the liquid can be withdrawn at any time to do the treatment |
Accessoriess
(1)Aerosol Generator: Produces controlled aerosols for testing containment and dispersion.
(2)Sensors and Detectors: Measure aerosol concentration, particle size, and decay over time.
(3)Chamber Components: Includes doors, seals, and panels to maintain a controlled environment.
(4)Control and Data Acquisition Unit: Monitors and records real-time test data.
Maintenance Information
(1)Routine Inspection: Check sensors, electrical connections, seals, and chamber integrity before each test.
(2)Cleaning: Wipe the chamber, sensors, and generator components to remove residues and prevent contamination.
(3)Calibration: Regularly verify sensor accuracy and aerosol generator output for consistent results.
(4)Storage: Keep the device in a dry, dust-free, and stable environment to ensure longevity and performance.
FAQ
1. What is a Spray Aerosol Enclosed Space Tester used for?
It is used to evaluate aerosol dispersion, containment, and filtration efficiency within enclosed spaces, providing critical data for safety and environmental control studies.
2. Which materials or systems can be tested?
The tester can assess enclosures, protective equipment, filters, ventilation systems, and materials that interact with airborne particles or aerosols.
3. How does the Spray Aerosol Enclosed Space Tester work?
A controlled aerosol is generated and introduced into the chamber, while sensors measure particle concentration, distribution, and decay to determine containment or filtration performance.
4. What safety features are included?
It is equipped with chamber seals, emergency stops, protective shields, and interlocks to ensure safe operation during aerosol testing.
5. How should the tester be maintained?
Regular maintenance includes inspecting sensors and seals, cleaning the chamber and generator components after each test, calibrating sensors periodically, and storing the device in a dry, dust-free environment.
