Torque Sensor Calibration Instrument
Category：Torsion Testing Machine
Introduction
The Torque Sensor Calibration Instrument is used to calibrate torque sensors and determine the relationship between the sensor output and the applied torque. The system uses standard weights and torque connection components to verify the measurement accuracy and reliability of torque sensors.
Application
Torque sensor calibration and verification
Torque measurement system calibration
Torque sensor accuracy inspection
Forward and reverse torque verification
Laboratory and industrial torque measurement calibration
Torque sensor calibration should be performed under controlled environmental conditions, considering temperature, relative humidity, sensor installation, and applied load.
The calibration process should minimize the effects of parasitic loads and bearing friction to improve measurement accuracy.
Parameters
| Item | Description |
|---|---|
| Calibration Method | Standard weight loading |
| Calibration Components | Weights, torque connectors, pulley, rotating tester, torque handle |
| Calibration Direction | Forward and reverse |
| Calibration Process | Zeroing → Weight Loading → Software Calibration → Reverse Verification |
| Measurement Stability | Generally 0.01 gf·cm–0.03 gf |
| Reverse Verification Difference | Average forward and reverse values when the difference exceeds 0.5 gf·cm |
| Control System | Industrial computer and test software |
Features
Standard weight loading method for torque sensor calibration.
Software-assisted calibration and data processing.
Supports forward and reverse torque verification.
Helps reduce the influence of installation and external loads.
Suitable for laboratory and industrial torque measurement systems.
