Transmission belt flammability and flame diffusion characteristics tester
Category：Flammability Tester
Introduction
Product Introduction:
The conveyor belt flammability and flame diffusion tester is suitable for testing the flammability and flame propagation characteristics of conveyor belts with textile body and steel cord conveyor belts and horizontal oriented conveyor belts.
Applicable standards:
AS 1334.10 1994 “Determination of flammability and flame propagation characteristics of conveyor belts”
ISO 340-2022 Conveyor belts – Flammability characteristics at laboratory scale – Requirements and test methods
Technical parameters:
Ignition time setting range: 0 —— 999.9s
Combustion timing range: 0 —— 999.9s
Bunsen burner: The inner diameter is 10.5mm
Bunsen burner rotation Angle: 0° —— 45°, adjustable
Thermocouple: Type K armor
Thermocouple display range: 0 —— 1300℃
Test flame temperature: 1000±20℃
Flame scale: 50 —— 150/180mm
Combustion chamber size: 500mm×500mm×500mm
Combustion gas: Propane gas, purity >95%
Volume: 555×651×738mm
Weight (approx) : ≈80Kg
Power supply: AC220V ±10%, 50 —— 60Hz
