Glazed Ceramic Tile Abrasion Tester
Category：Other
Introduction
Product Overview
The Glazed Ceramic Tile Abrasion Tester is a professional laboratory instrument designed to evaluate the surface wear resistance of glazed ceramic tiles. It operates by applying a specified abrasive material on the tile surface and grinding under controlled conditions. The resulting wear pattern is visually inspected to classify glaze durability.
This tester is widely used in ceramic tile manufacturing, R&D laboratories, quality control departments, and certification agencies. It supports simultaneous testing of multiple samples, ensuring efficient, standardized assessment of tile wear resistance.
Applicable Standards
The instrument complies with international and national standards:
ISO/DIS 10545-7:1996 – Ceramic Tiles – Surface Wear Resistance Test Method for Glazed Tiles
GB/T 3810.7-2016 – Test Method for Glaze Wear Resistance of Ceramic Tiles
Technical Specifications
| Parameter | Specification |
|---|---|
| Sample Dimensions | 100 × 100 mm |
| Number of Samples | 3 or 8 simultaneous (eight-head grinder); fewer samples feasible |
| Distance from Plate Center to Sample | 195 mm |
| Rated Speed of Supporting Plate | 300 rpm |
| Eccentricity | e = 22.5 mm |
| Metal Clamp (Rubber Sealed) | Inner diameter: Φ83 mm; Height: 25.5 mm; Test area per clamp: ~54 mm |
| Motor Power | 0.55 kW |
| Power Supply | 380 V, 50 Hz |
| Circular Motion Diameter | 45 mm |
| Observation Box Voltage | 220 V, 200 W |
| Lighting | Two fluorescent lamps, 6000–6500K, illuminance ~300 lx |
| Observation Box Dimensions | 610 × 610 × 610 mm |
Key Features
Innovative Design: Smooth operation, low noise, and user-friendly interface.
Simultaneous Testing: Up to 8 samples (or fewer) can be tested at the same time.
Automated Operation: Digital timer relay stops automatically after preset cycles; no manual monitoring required.
Durable Construction: Rubber-sealed clamps and robust mainframe ensure consistent and reliable testing results.
Observation Capability: Optional observation box allows visual inspection of wear patterns under standardized lighting conditions.
Included Accessories
LM test mainframe × 1
Steel balls (abrasive) × 1 set
F80 white corundum powder × 1 kg
Observation box (optional; additional cost)
FAQ
1. What is the main purpose of this tester?
It evaluates the surface wear resistance of glazed ceramic tiles by simulating abrasion with standardized abrasive materials under controlled motion.
2. How many samples can be tested at once?
The standard setup allows simultaneous testing of 3 or 8 samples. Fewer samples can also be tested as needed.
3. What are the power requirements?
The main unit requires 380 V, 50 Hz, and the optional observation box uses 220 V, 200 W.
4. What type of abrasive materials are used?
The tester uses steel balls in combination with F80 white corundum powder for standardized wear testing.
5. Is visual inspection standardized?
Yes. The optional observation box provides standardized lighting and positioning to accurately observe wear patterns in compliance with ISO and GB standards.
