Standard

EN 1569: Determines rolling load resistance of synthetic sports surfaces (e.g., PU, PVC, rubber).

EN 14904: Tests performance of multi-sport indoor flooring under repetitive mechanical stress.

DIN 18032-2: German standard for impact attenuation and deformation recovery in athletic facilities.

Product Advantages

1. Universal Compatibility

Sample Thickness Flexibility: Tests materials from 2mm to 50mm (flooring, shock pads, seams).

Adjustable Load Range: 50N to 500N customizable for basketball, volleyball, and multi-purpose courts.

2. Automated Precision

Speed & Cycle Control: Programmable 1–10 cycles/minute with auto-pause at set intervals.

Self-Leveling Wheel: Maintains 0.5mm contact consistency across uneven seams.

3. Unobstructed Visualization

High-Clarity Enclosure: Polycarbonate dome with anti-fog coating for 360° process monitoring.

LED Task Lighting: Shadow-free illumination for residual indentation inspection.

4. User-Centric Design

Plug-and-Play Calibration: Pre-loaded EN 1569 protocols with touchscreen load adjustment.

Ergonomic Access: Sliding front panel for quick sample changes.

5. Regulatory Compliance

CE & TÜV Certified: Meets EU machinery directives for laboratory equipment.

Audit-Ready Reporting: 21 CFR Part 11 compliant data logging.

Product Features

Rolling System:

Hardened Steel Wheel: 75mm diameter with 20° chamfer for seam simulation.

Pneumatic Load Application: ±1N accuracy via digital pressure regulator.

Control Panel:

7” TFT touchscreen with real-time cycle counter and load visualization.

USB/Ethernet ports for PC connectivity and remote diagnostics.

Safety Systems:

Emergency stop with E-Stop loop monitoring.

Overload protection at 110% of rated capacity.

Software Suite:

FloorDur Pro™: Auto-calculates deformation recovery (DIN 18032-2) and residual indentation.

Cloud Sport: Remote monitoring for global R&D teams.

Illumination:

Adjustable LED array (3.000–6.500K color temperature).

Auto-dimming function for operator comfort.

Accessories & Options

Standard Kit:

EN 1569-compliant steel rolling wheel.

Calibration weight set (50N–500N).

Software Add-Ons:

Batch Processor: Queue 24/7 unattended testing.

API Integration: Connect to MATLAB/Python for custom analytics.

Safety Upgrades:

Explosion-proof enclosure for solvent-resistant testing.

HEPA filtration for particle-sensitive labs.

Calibration Services:

Annual recalibration with NIST-traceable certificate.

Consumables:

10 × Replacement polycarbonate dome panels.

1L Silicone lubricant for high-cycle testing.

Technical Parameters
