Plastic Pipe Hydrostatic Pressure Burst Tester
Category：Other
Introduction
Product Introduction
The Plastic Pipe Hydrostatic Pressure Burst Tester is designed to evaluate the pressure resistance and burst strength of thermoplastic pipes under constant and short-term hydraulic pressure. The system supports a wide range of pipe materials including PVC, PE, PPR, and composite pipes, and provides accurate, repeatable results for quality control, R&D, and certification purposes. Its advanced microprocessor control and modular design allow precise testing while integrating seamlessly into laboratory networks.
Application Scope
Thermoplastic pipes: PVC, PE, PPR, and composite pipelines
Pipe diameters from 16 mm to 160 mm (expandable with adapters)
Quality assurance, certification testing, and R&D laboratories
Hydrostatic burst, constant pressure, and short-term failure testing
Applicable Standards
ISO 1167: Thermoplastics pipes – Determination of internal pressure resistance
ASTM D1598: Time-to-failure of plastic pipe under constant internal pressure
ASTM D1599: Short-time hydraulic pressure resistance of plastic pipe
ASTM F1335: Thermoplastic pipe hydrostatic testing
ISO 9080: Plastics piping systems – Long-term hydrostatic strength
CJ/T 108: Chinese standard for plastic pipe hydrostatic testing
Product Advantages
High Precision & Reliability: Microprocessor controller provides ±0.1% FS pressure accuracy; optional auto/manual calibration ensures traceable measurements.
Modular & Scalable: Expandable testing stations and compatible with diverse pipe types and diameters.
Space-Saving Efficiency: 45 stations in a compact footprint (<1 m²) optimize lab space.
Robust Performance: VFD-driven pump adjusts flow dynamically, reducing energy use and noise.
User-Centric Safety: Emergency stop, overpressure protection, and leak-proof fittings ensure operator safety.
Data Integrity: TCP/IP or Wi-Fi connection enables remote monitoring, multi-user access, and integration with analytics platforms.
Product Features
Smart Software Suite: Multi-user environment with role-based access control, wireless remote operation, sample database with barcode scanning, customizable ISO/ASTM-compliant reports.
Precision Engineering: Stainless steel test chamber with anti-corrosion coating, dual-circuit hydraulic system for rapid pressure stabilization, self-diagnostics for maintenance reminders.
Ergonomic Design: 7-inch multi-language touchscreen, adjustable stand height, mobile caster base for lab flexibility.
Technical Parameters
| Parameter | Specification |
|---|---|
| Pressure Range | 0–50 MPa (customizable up to 100 MPa) |
| Testing Stations | 45 (expandable to 60) |
| Pump Type | Variable Frequency Drive (VFD) |
| Power Supply | 220V/50Hz or 110V/60Hz (CE/UL certified) |
| Control System | PLC + HMI Touchscreen |
| Data Interface | Ethernet (TCP/IP), USB 2.0, Wi-Fi |
| Operating Environment | 5–40°C, ≤85% RH (non-condensing) |
| Dimensions (L×W×H) | 950 × 850 × 1800 mm |
| Weight | 450 kg (net) |
Accessories & Optional Modules
PipeTesting Pro™ Software: Lifetime updates for data acquisition and analytics
High-Accuracy Pressure Sensors: 0.05% FS accuracy (x3 units)
Quick-Connect Fittings Kit: Supports 16–160 mm pipe diameters
Spare Parts Pack: Seals, hoses, and calibration tools
Multilingual User Manual: PDF + hardcopy (English/Spanish)
ISO 17025 Calibration Certificate: NIST-traceable calibration
