Battery Film Drying Tunnel Furnace
Category：Tunnel Oven Production Line
Introduction
The battery film drying tunnel furnace is a high-efficiency continuous thermal processing equipment specially designed for film materials such as lithium battery electrode sheets, separators, and capacitor electrodes.It adopts a tunnel-type structure. Through precise temperature control and optimized air duct design, it can rapidly dry solvents or moisture on the surface of film materials.
Applications
Electrode Sheet Drying:
Used to remove solvents (such as NMP or water) after slurry coating on lithium battery positive and negative electrode sheets.
Separator Processing:
Used for drying or thermal modification after coating of battery separators.
Curing Treatment:
Used for thermal curing of specific battery auxiliary materials.
Parameters
| Parameter Item | Technical Specification |
|---|---|
| Working Temperature | Room temperature – 250℃ (adjustable) |
| Temperature Control Accuracy | ±1℃ |
| Heating Method | Hot air circulation / Infrared heating / Microwave heating (optional) |
| Conveyor Speed | 0.5 – 5 meters/minute (variable frequency speed regulation) |
| Tunnel Length | 6 – 30 meters (customized according to production capacity) |
| Furnace Belt Width | 300 – 1200 millimeters |
| Power Supply Requirement | 384V, 50Hz, Three-phase five-wire system |
Features
Precise Temperature Control:
Independent temperature control in multiple sections ensures accurate adjustment of each heating zone.
Uniform Drying:
The double-sided air duct design ensures even airflow distribution and uniform drying performance.
High Efficiency and Energy Saving:
The hot air circulation system effectively recycles heat energy and reduces energy consumption.
Extremely Low Dust:
Built-in high-efficiency filtration system minimizes dust contamination during the drying process.
Intelligent Explosion Protection:
Equipped with solvent concentration alarms and exhaust systems to ensure safe operation.
