Electronic Water Pump Moisture Drying Tunnel Furnace
Category：Tunnel Oven Production Line
Introduction
The electronic water pump moisture drying tunnel furnace is a continuous industrial heating equipment specially designed for rapidly drying residual moisture from new energy vehicle electronic water pumps, industrial circulating water pumps, and other products after cleaning, testing, or coating processes.The equipment adopts a tunnel-type structure combined with a conveyor system to achieve automatic continuous loading and unloading of products. Through precise temperature control and hot air circulation systems, it rapidly evaporates and removes residual moisture inside and on the surface of water pumps, preventing rust formation and avoiding impacts on subsequent assembly processes.
Applications
Drying After Cleaning:
Used to remove residual moisture from water pump housings after machining and cleaning processes.
Drying After Airtightness Testing:
Used for rapidly drying internal flow channels after water pressure testing or airtightness testing of water pumps.
Preheating Before Coating Curing:
Used for dehydration and drying treatment before surface spraying or adhesive dispensing on water pumps.
Integration with Continuous Production Lines:
Connected with front-end and back-end automated production lines to achieve large-scale, unmanned, and continuous drying of water pumps.
Parameters
| Parameter Item | Technical Specification |
|---|---|
| Equipment Dimensions | Approximately L 6000 millimeters × W 1200 millimeters × H 1600 millimeters (customized according to production capacity) |
| Drying Zone Length | 4000 millimeters (divided into independent temperature control zones) |
| Working Temperature Range | Room temperature (RT) + 10℃ to 200℃ (commonly used working temperature: 80℃ – 120℃) |
| Temperature Control Accuracy | ±1℃ |
| Temperature Uniformity | ±3℃ (no-load condition) |
| Conveyor Type | Stainless steel mesh belt / Teflon mesh belt / Chain-type stainless steel pallet conveyor |
| Conveyor Speed | 0.5 – 5 meters/minute (adjustable by variable frequency speed regulation) |
| Heating Power | 30 kilowatts – 60 kilowatts (depending on equipment specifications) |
| Power Supply Specification | Three-phase five-wire system, AC 380V, 50Hz |
Features
High-Efficiency Hot Air Circulation:
The equipment adopts a multi-side air circulation design with strong and uniform airflow, ensuring that moisture inside blind holes and complex flow channels of water pumps is completely removed.
Precise Zoned Temperature Control:
The tunnel furnace is divided into a preheating zone, high-temperature drying zone, and constant temperature zone. Each zone is independently temperature controlled, ensuring stable heating and preventing electronic components from being damaged by sudden temperature changes.
Energy-Saving Thermal Insulation Design:
The equipment body adopts high-density aluminum silicate fiber cotton insulation. The outer shell temperature remains close to room temperature, minimizing heat loss and significantly reducing power consumption.
Intelligent Control System:
Equipped with PLC control and touch screen operation, supporting real-time temperature curve display, data storage, and automatic fault alarms.
Flexible Speed Adjustment:
The conveyor system adopts variable frequency speed regulation, allowing flexible adjustment of drying time according to water pump specifications and surface moisture conditions.
