Film Coating Tunnel Oven
Category：Tunnel Oven Production Line
Introduction
The Film Coating Tunnel Oven is an industrial-grade continuous heat treatment equipment specially designed for drying and curing coated films.It adopts a tunnel-type structure combined with a conveyor transmission system, allowing coated films to continuously pass through multiple heating zones. Through precise control of temperature and airflow speed, the equipment can rapidly cure, dry, or dehydrate surface coatings on films, making it a key processing system in film manufacturing and post-processing industries.
Applications
1. Film Coating Curing
Used for thermal drying and curing of surface coatings on:
Optical films
Photosensitive films
Other functional coated films
2. Polymer Film Drying
Widely used for curing inks and functional coatings on film substrates such as:
PET films
PI films
PVC films
3. Composite Material Heat Treatment
Suitable for:
Heat pressing and forming of multi-layer film composites
Adhesive curing after lamination processes
4. Electronic Insulation Material Baking
Applied for continuous dehydration and drying of coatings on flexible circuit board substrates and electronic insulation materials.
Product Parameters
| Parameter Item | Technical Specification |
|---|---|
| Heating Energy Source | Electric heating / Steam heating / Infrared heating / Natural gas heating |
| Maximum Operating Temperature | Room Temperature – 250℃ (Customized up to 400℃ according to process requirements) |
| Temperature Control Accuracy | ±1℃ |
| Conveyor Speed | 0.5 – 15 m/min (Variable frequency stepless speed adjustment) |
| Conveyor Belt Material | Teflon mesh belt / Stainless steel mesh belt / Chain conveyor |
| Total Tunnel Length | 6 m – 30 m (Multiple independent temperature zones) |
Features
1. High Thermal Efficiency
The equipment adopts a hot air circulation system with multiple independent temperature control zones, ensuring uniform temperature distribution and stable coating curing quality.
2. High Cleanliness Performance
Equipped with high-efficiency filters such as HEPA filters, ensuring a clean internal environment. The oven cleanliness level can reach Class 100 or Class 1000 cleanroom standards according to configuration requirements.
3. Precise Speed Control
The transmission system operates smoothly to prevent film stretching, deformation, or surface damage during the drying process.
4. Intelligent and Safe Operation
The system is equipped with:
Over-temperature alarm
Exhaust gas ventilation system
PLC intelligent touchscreen control
to achieve safe and automated operation.
