Hanging Type Baking Oven
Category：Tunnel Oven Production Line
Introduction
The hanging type baking oven is a non-standard customized drying system designed for continuous production lines such as wheel hub coating and hanging dip coating. It uses a suspension conveying structure, combined with multi-zone heating and cooling, to ensure stable operation, uniform heating, and clean processing conditions.
Applications
Suitable for new energy, optical and optoelectronic, glass, precision hardware, and coating industries.
Specifications
| Item | Specification |
|---|---|
| Overall Dimensions | L8600 × W1200 × H2237 mm |
| Heating Zone Length | 6000 mm |
| Inlet Section Length | 500 mm |
| Outlet Section Length | 500 mm |
| Inlet Size | Height 1000 mm × Width 600 mm |
| Max Product Size | H800 × Ø400 mm |
| Temperature Zones | 3 independent zones with separate control |
| Cooling Section | Natural cooling (300 mm) + forced air cooling (1300 mm) |
| Filtration System | Medium-efficiency filters on air inlet and both sides |
| Cleanliness Level | Within Class 20,000 |
| Pressure Design | Slight positive pressure inside chamber |
Features
Hanging conveyor design for stable transport of coated products
Three independent temperature zones with precise control
Integrated heating and cooling for continuous operation
Built-in filtration system ensures clean processing environment
Positive pressure design prevents dust contamination
Combination of natural and forced cooling improves efficiency
Suitable for coating and drying of complex-shaped parts
