Knitted Fabric Preheating and Setting Tunnel Furnace
Category：Tunnel Oven Production Line
Introduction
The knitted fabric preheating and setting tunnel furnace is a continuous thermal processing equipment specially developed for knitted fabrics.The equipment uses precisely controlled high-temperature airflow to uniformly heat the fabric after width adjustment, eliminating residual stress inside the fibers.It can effectively prevent knitted fabrics from developing edge curling, deformation, and dimensional instability during subsequent processing. It is a key equipment for modern textile dyeing and finishing enterprises to improve product competitiveness.
Applications
Stress Elimination:
Smooths and stabilizes the internal fiber structure of knitted fabrics.
Dimensional Stability:
Controls fabric shrinkage rate to prevent deformation.
Edge Curling Prevention:
Solves the problem of edge curling in open-width knitted fabrics.
Baking and Color Fixing:
Used for functional finishing agent baking and fabric setting processes.
Parameters
| Parameter Item | Technical Specification |
|---|---|
| Heating Method | Natural gas / Electric heating / Heat transfer oil / Steam |
| Working Temperature | 100℃ – 220℃ (continuously adjustable) |
| Operating Line Speed | 5 – 50 meters/minute |
| Effective Working Width | 1800 millimeters – 2400 millimeters (customizable) |
| Temperature Control Accuracy | ±1℃ |
| Transmission Method | Variable frequency speed-controlled mesh belt transmission / Chain guide rail transmission |
Features
Precise Temperature Control:
The equipment adopts a segmented independent circulating air duct design, ensuring extremely small temperature differences inside the chamber.
Stable Operation:
The ultra-wide mesh belt conveyor combined with variable frequency speed regulation enables tension-free heating of fabrics.
Energy Saving and High Efficiency:
The high-density insulation layer reduces heat loss, and the special hot air circulation system saves up to 30% energy.
Intelligent Operation:
The PLC touch screen allows one-button setting of process parameters and supports recipe storage.
