Natural Gas Tunnel Furnace
Category：Tunnel Oven Production Line
Introduction
The Natural Gas Tunnel Furnace is a large-scale industrial heating and baking equipment that utilizes a continuous tunnel structure for efficient heating processing. Powered primarily by natural gas, the equipment uses an advanced combustion system combined with hot air circulation or radiation heating technology to complete processes such as drying, curing, baking, and aging while materials are continuously transported through the conveyor system.
Applications
Food Industry:
Used for continuous large-scale baking of bread, biscuits, pastries, and meat products.
Coating Industry:
Used for curing surface coatings after spray painting of automotive parts, hardware components, plastic parts, and other products.
Electronic and Electrical Industry:
Used for drying and aging processes of transformers, motor windings, and circuit boards after impregnation treatment.
New Materials Industry:
Used for high-temperature dehydration, drying, and sintering of chemical materials, ceramics, composite materials, and other products.
Product Parameters
| Parameter Item | Technical Specification |
|---|---|
| Equipment Length | 10 m – 60 m (customizable according to production line requirements) |
| Mesh Belt Width | 600 mm – 2000 mm |
| Working Temperature | Room temperature – 400℃ (high-temperature models up to 600℃) |
| Temperature Control Accuracy | ±1℃ – ±2℃ |
| Conveyor Speed | 0.5 m/min – 5 m/min (variable frequency adjustable) |
| Natural Gas Pressure | 2 kPa – 5 kPa |
Features
High Efficiency and Energy Saving:
Natural gas provides high calorific value and complete combustion, significantly reducing operating costs compared with electric heating systems.
Precise Temperature Control:
Adopts a multi-section independent temperature control system, allowing accurate adjustment of temperature in different furnace zones.
Uniform Heating Performance:
The scientifically designed hot air circulation system ensures uniform heating of both the product surface and internal core.
High Automation Level:
Equipped with PLC intelligent control, enabling seamless integration with upstream and downstream automated production lines.
Safe and Reliable Operation:
Features multiple safety protection systems, including gas leakage alarms, flame failure protection, and over-temperature power-off protection.
