Precision Tunnel Oven G-C3500A
Category：Tunnel Oven Production Line
Introduction
The Precision Tunnel Oven G-C3500A is a compact and efficient continuous heating system designed for precision drying and curing processes. The equipment adopts an imported medium-wave IR heating system with PID temperature control, providing fast heating response, stable temperature performance, and energy-efficient operation.
The tunnel oven features a stainless steel conveyor system, adjustable conveyor speed, sealed inner chamber structure, and optimized insulation design. It is suitable for applications requiring controlled heating, uniform temperature distribution, and stable product transportation.
Applications
The Precision Tunnel Oven G-C3500A is widely used for precision drying, heating, curing, and thermal processing of electronic components and industrial products.
Typical applications include:
Electronic component drying and curing
Precision parts heating processes
Optical and electronic material processing
Adhesive curing applications
Small-size product thermal treatment
Laboratory and production line heating processes
The conveyor width and heating zone design can be customized according to different product sizes and production requirements.
Specifications
| Item | Specification |
|---|---|
| Model | G-C3500A Precision Tunnel Oven |
| Power Supply | AC380V 3Φ 50Hz |
| Power Capacity | 20KVA |
| External Dimension | L3500 × W850 × H1460mm (Reference size) |
| Internal Chamber Dimension | L3500 × W480 × H300mm (Reference size) |
| Conveyor Width | 350mm |
| Conveyor Height | 940 ± 20mm |
| Conveyor Type | Stainless steel conveyor mesh |
| Conveyor Speed | 0.2–2.0m/min adjustable |
| Loading Section Length | 300mm |
| Heating Section Length | 2000mm |
| Cooling Section Length | 500mm |
| Discharge Section Length | 300mm |
| Temperature Control Zone | 1 heating control zone |
| Temperature Range | +50℃ to 150℃ (Common operating temperature up to 200℃) |
| Temperature Uniformity | ±5% (Empty chamber test) |
| Heating System | Imported medium-wave IR heating tube with reflector |
| Temperature Controller | Imported digital temperature controller with PID automatic tuning |
| Heating Control Output | SCR power adjustment output |
| Outer Chamber Material | SS41 steel plate with 60# light sand texture coating |
| Inner Chamber Material | SUS201 stainless steel |
| Insulation Material | High-density environmentally friendly ceramic fiber insulation |
| Insulation Thickness | 100mm |
| Air Exhaust System | Stainless steel exhaust outlet with adjustable control |
| Control Panel | Temperature controller, power indicator, inverter, fault indicator, buzzer, start switch, heating switch |
| Safety Protection | Leakage protection, over-temperature protection, overload protection |
Features
(1) Precision Temperature Control
Equipped with PID automatic temperature control technology and SCR power regulation, ensuring stable heating performance and accurate temperature management.
(2) Fast and Efficient Heating
The imported medium-wave IR heating tube provides rapid temperature rise, high heating efficiency, long service life, and convenient maintenance.
(3) Stable Conveyor Operation
The stainless steel conveyor mesh combined with frequency converter speed adjustment enables smooth transportation without product deviation or interruption.
(4) Optimized Thermal Insulation Design
High-density ceramic fiber insulation reduces heat loss, improves energy efficiency, and maintains stable internal temperature conditions.
(5) Clean and Durable Chamber Structure
The inner chamber adopts SUS201 stainless steel with full argon welding sealing, reducing contamination risks and improving equipment durability.
(6) Easy Maintenance Design
The heating section side insulation covers and top cover are removable, allowing convenient inspection and maintenance.
(7) Safety Protection System
Integrated safety functions include leakage protection, overload protection, and over-temperature protection to improve operational safety.
(8) Customizable Configuration
Conveyor width, heating length, and equipment dimensions can be customized according to customer production requirements.
